B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 55 -

1324

Coordinate value of stored stroke check 3 in the positive direction on each

axis

1325

Coordinate value of stored stroke check 3 in the negative direction on each

axis

[Data type] 2-word axis

[Unit of data]

Increment system IS-A IS-B IS-C Unit

Millimeter machine 0.01 0.001 0.0001 mm

Inch machine 0.001 0.0001 0.00001 inch

Rotation axis 0.01 0.001 0.0001 deg

[Valid data range] -99999999 to 99999999

Set the coordinate values of stored stroke check 3 in the positive

and negative directions for each axis in the machine coordinate system.

The area inside the checks set in the parameter is inhibited.

NOTE

Specify diameters for any axis for which diameter

programming is specified.

1326

Coordinate value II of stored stroke check 1 in the positive direction on each

axis

1327

Coordinate value II of stored stroke check 1 in the negative direction on each

axis

[Data type] 2-word axis

[Unit of data]

Increment system IS-A IS-B IS-C Unit

Millimeter machine 0.01 0.001 0.0001 mm

Inch machine 0.001 0.0001 0.00001 inch

Rotation axis 0.01 0.001 0.0001 deg

[Valid data range] -99999999 to 99999999

Set the coordinate values of stored stroke check 1 in the positive and

negative directions for each axis in the machine coordinate system.

The tool cannot enter the area outside the checks set in the parameter.

The inhibition area set in the parameter is enabled when bit 2 (LMS)

of parameter No. 1300 is 1 and stored stroke limit switching signal

EXLM <G007#6> is 1.

NOTE

1 Specify diameter values for any axes for which

diameter programming is specified.

2 These parameters are invalid if bit 2 (LMS) of

parameter No. 1300 is set to 0, or if stored stroke

limit switching signal EXLM <G007#6> is set to 0.

In such a case, the settings of parameters No.

1320 and 1321 are used, instead.
