4.DESCRIPTION OF PARAMETERS B-64120EN/01

- 296 -

4.30 PARAMETERS OF PATTERN DATA INPUT

6101 First variable number displayed on pattern data screen 1

6102 First variable number displayed on pattern data screen 2

6103 First variable number displayed on pattern data screen 3

6104 First variable number displayed on pattern data screen 4

6105 First variable number displayed on pattern data screen 5

6106 First variable number displayed on pattern data screen 6

6107 First variable number displayed on pattern data screen 7

6108 First variable number displayed on pattern data screen 8

6109 First variable number displayed on pattern data screen 9

6110 First variable number displayed on pattern data screen 10

[Data type] Word

[Valid data range] 0, 100 to 199, 500 to 999

These parameters specify the first variable number displayed on the

pattern data screen selected from the pattern menu screen. When 0 is

set, 500 is assumed.
