0i/0i Mate - Model C Parameter manual Page 283

Parameter manual

Page of 414

/ 414

B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 271 -

Position control loop gain for the spindle and tapping axis in rigid tapping

using the second spindle (common to all the gears)

5341

Position control loop gain for the spindle and tapping axis in rigid tapping

using the second spindle (first-stage gear)

5342

Position control loop gain for the spindle and tapping axis in rigid tapping

using the second spindle (second-stage gear)

5343

NOTE

After these parameters have been set, the power

must be turned off then back on for the settings to

become effective.

[Data type] Word

[Unit of data] 0.01 s

-1

[Valid data range] 1 to 9999

Each of these parameters is used to set a position control loop gain for

the spindle and tapping axis in rigid tapping using the second spindle.

NOTE

1 To use a varied loop gain on a gear-by-gear basis,

set parameter No.5341 to 0, and set a loop gain for

each gear in parameters No.5342 and No.5343.

2 This parameter is enabled when the SPR

parameter (bit 1 of parameter No.5204) is set to 1.

Positional deviation limit imposed during tapping axis movement in rigid

tapping using the second spindle

5350

[Data type] 2-word

[Unit of data] Detection unit

[Valid data range] 1 to 99999999

This parameter sets a positional deviation limit imposed during

tapping axis movement in rigid tapping using the second spindle.

NOTE

This parameter is enabled when the SPR

parameter (bit 1 of parameter No.5204) is set to 1.
