0i/0i Mate - Model C Parameter manual Page 165

Parameter manual
B-64120EN/01 4.DESCRIPTION OF PARAMETERS
- 153 -
#7 #6 #5 #4 #3 #2 #1 #0
3116 MDC T8D COA FOV PWR
[Data type] Bit
PWR Alarm No.100 (parameter enable) :
0 : Clear by
+ key
1 : Clear by
key
FOV In the field of specified feedrate F on the program check screen,
0 : The specified feedrate is displayed.
1 : (Specified feedrate) x (override) is displayed.
COA While an external alarm state is present or while an external message
is being displayed, automatic screen erasure is:
0 : Performed.
1 : Not performed.
T8D T codes that are always displayed are displayed with:
0 : Four digits.
1 : Eight digits.
This parameter expands the T code display to eight digits for
the continuous S or T display (bit 2 (DPS) of parameter No. 3105 is
set to 1).
MDC Maintenance information by operating soft key :
0 : All clear disable.
1 : All clear enable.
#7 #6 #5 #4 #3 #2 #1 #0
ANS SPP
3117
ANS SMS
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
[Data type] Bit
SMS On the program check screen, the soft key to enable or disable the
graph of spindle speed and load is:
0 : Not displayed.
1 : Displayed.
SPP On the diagnostic screen, spindle position data (the number of pulses
from the position coder, detected after the detection of the
one-revolution signal) is:
0 : Not displayed.
1 : Displayed. (Diagnostic Nos. 445 to 447)
ANS The subscript of each axis name set in parameter No. 3131 is
displayed:
0 : Only when the current position is displayed.
1 : On the parameter screen, diagnosis screen, alarm screen, and
alarm history screen as well as when the current position is
displayed.
#7 #6 #5 #4 #3 #2 #1 #0
