4.DESCRIPTION OF PARAMETERS B-64120EN/01
- 170 -
GSB, GSC The G code system is set.
GSC GSB G code
0 0 G code system A
0 1 G code system B
1 0 G code system C
#7 #6 #5 #4 #3 #2 #1 #0
G23 CLR FPM G91 G01
3402
G23 CLR G91 G19 G18 G01
[Data type] Bit
G01 Mode entered when the power is turned on or when the control is
cleared
0 : G00 mode (positioning)
1 : G01 mode (linear interpolation)
G18 and G19 Plane selected when power is turned on or when the control is cleared
G19 G18 G17, G18 or G19 mode
0 0 G17 mode (plane XY)
0 1 G18 mode (plane ZX)
1 0 G19 mode (plane YZ)
G91 When the power is turned on or when the control is cleared
0 : G90 mode (absolute command)
1 : G91 mode (incremental command)
FPM When the power is turned on
0 : Feed per revolution on
1 : Feed per minute mode
CLR Reset button on the MDI panel, external reset signal, reset and rewind
signal, and emergency stop signal
0 : Cause reset state.
1 : Cause clear state.
For the reset and clear states, refer to Appendix in the Operator's
Manual.
G23 When the power is turned on
0 : G22 mode (stored stroke check on)
1 : G23 mode (stored stroke check off)
#7 #6 #5 #4 #3 #2 #1 #0
3403 AD2 CIR
[Data type] Bit
CIR When neither the distance (I, J, K) from a start point to the center nor
an arc radius (R) is specified in circular interpolation (G02, G03):
0 : The tool moves to an end point by linear interpolation.
1 : P/S alarm No.022 is issued.
AD2 Specification of the same address two or more times in a block is:
0 : Enabled (Next specification is enabled.)
1 : Disabled (P/S alarm No.5074)
