4.DESCRIPTION OF PARAMETERS B-64120EN/01

- 350 -

MIRx When a PMC axis control command is issued in mirror image mode,

the mirror image is:

0 : Not considered.

1 : Considered.

This parameter is valid when PMC signals MI1 to MI4 <G106#0-3>

are set to "1" or bit 0 (MIRx) of parameter No. 0012 is set to "1".

8010 Selection of the DI/DO group for each axis controlled by the PMC

[Data type] Byte axis

[Valid data range] 1 to 4

Specify the DI/DO group to be used to specify a command for each

PMC-controlled axis.

Value Description

1 DI/DO group A (G142 to G153) is used.

2 DI/DO group B (G154 to G165) is used.

3 DI/DO group C (G166 to G177) is used.

4 DI/DO group D (G178 to G189) is used.

8020 Low-speed feedrate at reference position return in axis control by PMC (FL)

[Data type] Word axis

[Unit of data, valid data range]

Valid data range

Increment system Units of data

IS-B IS-C

Millimeter machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Rotation axis 1 deg/min 6 to 15000 6 to 12000

This parameter specifies the low-speed feedrate at a reference position

return on a PMC-controlled axis (FL).

NOTE

If 0 is specified, the value of parameter No. 1425 is

used.
