B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 341 -

Control axis number of tool rotation axis for polygon turning

7610

[Data type] Byte

[Valid data range] 1, 2, 3, . . . number of control axes

This parameter sets the control axis number of a rotation tool axis

used for polygon turning.

Movement of tool rotation axis per revolution

7620

[Data type] 2-word

Input increment IS-A IS-B IS-C Unit

Rotation axis 0.01 0.001 0.0001 deg

[Valid data range] 1 to 9999999

This parameter sets the movement of a tool rotation axis per

revolution.

Maximum allowable speed for the tool rotation axis (polygon

synchronization axis) 7621

[Data type] Word

[Unit of data] min

-1

[Valid data range] 0 to 1.2 × 10

/ Set value of the parameter No.7620

This parameter sets the maximum allowable speed of the tool rotation

axis (polygon synchronization axis).

If the speed of the tool rotation axis (polygon synchronization axis)

exceeds the specified maximum allowable speed during polygon

turning, the speed is clamped at the maximum allowable speed. When

the speed is clamped at a maximum allowable speed, however,

synchronization between the spindle and tool rotation axis (polygon

synchronization axis) is lost. And, when the speed is clamped, P/S

alarm No.5018 is issued.

Multiplier influencing the slave spindle speed

7635

[Data type] Byte

[Unit of data] Slave spindle (min

-1

)/master spindle (min

-1

)

[Valid data range] 1 to 9

Set up a multiplier that will act on the distance through which the

slave spindle is to move.

In speed ratio control, the relationship between the speeds of the

spindles is:

Slave spindle speed = master spindle speed ×

setting of parameter

No. 7635
