0i/0i Mate - Model C Parameter manual Page 325

Parameter manual
B-64120EN/01 4.DESCRIPTION OF PARAMETERS
- 313 -
6752 Operation time (integrated value of time during automatic operation) II
The following parameter can be set at "Setting screen".
[Data type] 2-word
[Unit of data] min
[Valid data range] 0 to 99999999
This parameter displays the integrated value of time during automatic
operation (neither stop nor hold time included).
The actual time accumulated during operation is the sum of this
parameter No. 6751 and parameter No. 6752.
6753 Integrated value of cutting time I
The following parameter can be set at "Setting screen".
[Data type] 2-word
[Unit of data] msec
[Valid data range] 1 to 60000
6754 Integrated value of cutting time II
The following parameter can be set at "Setting screen".
[Data type] 2-word
[Unit of data] min
[Valid data range] 0 to 99999999
This parameter displays the integrated value of a cutting time that is
performed in cutting feed such as linear interpolation (G01) and
circular interpolation (G02 or G03).
The actual time accumulated during cutting is the sum of this
parameter No. 6753 and parameter No. 6754.
6755
Integrated value of general-purpose integrating meter drive signal (TMRON)
ON time I
The following parameter can be set at "Setting screen".
[Data type] 2-word
[Unit of data] msec
[Valid data range] 0 to 60000
6756
Integrated value of general-purpose integrating meter drive signal (TMRON)
ON time II
The following parameter can be set at "Setting screen".
[Data type] 2-word
[Unit of data] min
[Valid data range] 0 to 99999999
This parameter displays the integrated value of a time while input
signal TMRON <G053#0> from PMC is on.
The actual integrated time is the sum of this parameter No. 6755 and
parameter No. 6756.
6757 Operation time (integrated value of one automatic operation time) I
