0i/0i Mate - Model C Parameter manual Page 379

Parameter manual
B-64120EN/01 4.DESCRIPTION OF PARAMETERS
- 367 -
4.49 PARAMETERS OF SEQUENCE NUMBER COMPARISON
AND STOP
8341 Program number subject to comparison and stop
[Data type] Word
[Valid data range] 0 to 9999
This parameter sets the program number, including a sequence number,
subject to sequence number comparison and stop. Parameter No.8342
is used to set a sequence number subject to check termination.
NOTE
A program number can also be set on the setting
screen. If a program number is set on the setting
screen, the value of the parameter is changed
accordingly.
8342 Sequence number subject to comparison and stop
[Data type] 2-word
[Valid data range] 0 to 9999
This parameter sets the sequence number subject to sequence number
comparison and stop.
If the block containing the sequence number set with this parameter is
executed while the program set with parameter No.8341 is being
executed, a single block stop occurs after the block is executed. At this
time, the setting is automatically set to -1. Upon power-up, the setting
is automatically set to 0.
NOTE
A sequence number can also be set by using the
setting screen. If a sequence number is set on the
setting screen, the value of the parameter is
changed accordingly.
