0i/0i Mate - Model C Parameter manual Page 259

Parameter manual

Page of 414

/ 414

B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 247 -

5163

M code that specifies the peck drilling cycle mode of a small diameter

[Data type] 2-word

[Valid data range] 1 to 99999999

This parameter sets an M code that specifies the peck drilling

cycle mode of a small diameter.

5164

Percentage of the spindle speed to be changed when the tool is retracted

after an overload torque signal is received

[Data type] Byte

[Unit of data] %

[Valid data range] 1 to 255

This parameter sets the percentage of the spindle speed to be changed

when the tool is retracted because the overload torque signal is

received in a peck drilling cycle of a small diameter.

S2 = S1 × d1 ÷ 100

S1: Spindle speed to be changed

S2: Spindle speed changed

d1 is set as a percentage.

5165

Percentage of the spindle speed to be changed when the tool is retracted

without an overload torque signal received

[Data type] Byte

[Unit of data] %

[Valid data range] 1 to 255

This parameter sets the percentage of the spindle speed to be changed

when the tool is retracted without the overload torque signal received

in a peck drilling cycle of a small diameter.

S2 = S1 × d2 ÷ 100

S1: Spindle speed to be changed

S2: Spindle speed changed

d2 is set as a percentage.
