B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 83 -

1 : Bell-shaped acceleration/deceleration after interpolation is

applied.

NOTE

This parameter is effective only when the function

of bell-shaped acceleration/deceleration after

interpolation in cutting feed is provided. If the

function is not provided, the setting in CTLx, bit 0 of

parameter No.1610, determines the type of

acceleration/deceleration irrespective of the setting

in this parameter.

JGLx Acceleration/deceleration in jog feed

0 : Exponential acceleration/deceleration is applied.

1 : Linear acceleration/deceleration after interpolation or bell-shaped

acceleration/deceleration after interpolation is applied

(depending on which is used for cutting feed).

1620

Time constant T or T

used for linear acceleration/deceleration or

bell-shaped acceleration/deceleration in rapid traverse for each axis

[Data type] Word axis

[Unit of data] ms

[Valid data range] 0 to 4000

Specify a time constant used for acceleration/deceleration in rapid

traverse for each axis.

(1) When bell-shaped acceleration/deceleration is set

Set time constant T

for bell-shaped acceleration/deceleration in

this parameter, and set time constant T

in parameter No. 1621.

(2) When linear acceleration/deceleration is set

Set time constant T for linear acceleration/deceleration in this

parameter, and set 0 in parameter No. 1621.

NOTE

1 When parameter No.1621 (time constant T

used

for bell-shaped acceleration/deceleration in rapid

traverse) is set to 0, linear

acceleration/deceleration is applied in rapid

traverse even if the function is provided. In this

case, this parameter stands for a time constant

used in linear acceleration/deceleration in rapid

traverse.

2 Depending on the set time constant values, a

movement may be made at a feedrate a little lower

than the rapid traverse rate for a certain time

before the rapid traverse rate is attained by

acceleration. To prevent this, set the time

constants to a multiple of 8.
