0i/0i Mate - Model C Parameter manual Page 400

Parameter manual
4.DESCRIPTION OF PARAMETERS B-64120EN/01
- 388 -
13612
Acceleration change time when AI contour control is used (bell-shaped)
(precision level 1)
13613
Acceleration change time when AI contour control is used (bell-shaped)
(precision level 10)
[Data type] Byte
[Unit of data] msec
[Valid data range] 1 to 100
These parameters set an acceleration change time (bell-shaped) with
emphasis placed on speed (precision level 1) and an acceleration
change time (bell-shaped) with emphasis placed on precision
(precision level 10) in AI contour control.
13620
Permissible acceleration when advanced preview control, AI advanced
preview control, or AI contour control is used (precision level 1)
13621
Permissible acceleration when advanced preview control, AI advanced
preview control, or AI contour control is used (precision level 10)
[Data type] 2-word axis
[Unit of data]
Increment system Unit
Millimeter machine 0.001mm/sec
2
[Valid data range] 0 to 99999999
These parameters set a permissible acceleration with emphasis placed
on speed (precision level 1) and a permissible acceleration with
emphasis placed on precision (precision level 10) in advanced preview
control, AI advanced preview control, or AI contour control.
13622
Time constant of acceleration/deceleration after interpolation
(precision level 1)
13623
Time constant of acceleration/deceleration after interpolation
(precision level 10)
[Data type] Word axis
[Unit of data] msec
[Valid data range] See the description of parameter No. 1768.
These parameters set a time constant of linear
acceleration/deceleration after interpolation with emphasis placed on
speed (precision level 1) and a time constant of linear
acceleration/deceleration after interpolation with emphasis placed on
precision (precision level 10).
The linear or bell-shaped type is selected by bit 3 (BS2) and bit 6
(LS2) of parameter No. 1602.
Parameter No.1602
LS2(#6) BS2(#3)
Acceleration/deceleration
1 0 Selects linear acceleration/deceleration after cutting
feed interpolation.
0 1 Selects bell-shaped acceleration/deceleration after
cutting feed interpolation.
