4.DESCRIPTION OF PARAMETERS B-64120EN/01

- 366 -

8326

Difference between master axis and slave axis reference counters

[Data type] 2-word axis

[Unit of data] Detection unit

[Valid data range] -99999999 to 99999999

The difference between the master axis reference counter and slave

axis reference counter (master axis and slave axis grid shift) is

automatically set when automatic setting for grid positioning is

performed. Then, the difference is transferred together with an

ordinary grid shift value to the servo system when the power is turned

on.

This parameter is set with a master axis.

8327

Torque difference alarm detection timer

[Data type] Word axis

[Unit of data] ms

[Valid data range] 0 to 4000

This parameter sets a time from the servo preparation completion

signal, SA (F000#6), being set to 1 until torque difference alarm

detection is started in simple synchronous control. A fraction of less

than 16 msec is rounded up.

Example:

Setting = 100: The specification of 112 msec is assumed.

Set this parameter with a master axis. If 0 is set in this parameter,

the specification of 512 msec is assumed.
