Series 0i - Model A Connection manual (Function) Page 147

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

4. REFERENCE POSITION ESTABLISHMENT

131

[Classification] Input signal

[Function] This signal selects manual reference position return. Manual reference

position return is a kind of jog feed. Therefor, to select manual reference

position return, it is required that the jog mode be selected and that the

manual reference position return selection signal be set to “1”.

[Operation] When the manual reference position return selection signal is set to “1”,

the control unit becomes as described below.

D If jog feed mode is not selected, the control unit ignores the manual

reference position return selection signal.

D If jog mode is selected, manual reference position return is enabled.

In this case, manual reference position return selection check signal

MREF turns to “1”.

NOTE

If the ZRN status changes from “0” to “1” or “1” to “0” during

jog feed, the feedrate is decelerated to 0. Then, to make

reference position return or jog feed, turn feed axis and

direction selection signal to “0” then set it to “1”.

[Classification] Output signal

[Function] This signal reports that manual reference position return has been selected

once.

[Output condition] This signal turns to “1” when:

⋅ Manual reference position return has been selected.

The signal turns to “0” when:

⋅ The selection of manual reference position return has terminated.

Signal

Manual reference

position return selection

signal (ZRN) <G043#7>

Manual reference

position return selection

check signal MREF

<F004#5>
