B–63503EN–1/01

A. INTERFACE BETWEEN CNC AND PMC

851

Address

Refer-

ence

Item

series

Symbol Signal name

F139#1 Following zero checking signal (PMC axis control) ECKZD f f 15.1

F139#2 Alarm signal (PMC axis control) EIALD f f 15.1

F139#3 Auxiliary function executing signal (PMC axis control) EDEND f f 15.1

F139#4 Axis moving signal (PMC axis control) EGEND f f 15.1

F139#5 Positive-direction overtravel signal (PMC axis control) EOTPD f f 15.1

F139#6 Negative-direction overtravel signal (PMC axis control) EOTND f f 15.1

F139#7

Axis control command read completion signal (PMC axis

control)

EBSYD f f 15.1

F140#0 Auxiliary function strobe signal (PMC axis control) EMFD f f 15.1

F140#1 Buffer full signal (PMC axis control) EABUFD f f 15.1

F141,F151 Auxiliary function code signal (PMC axis control) EM11D to EM48D f f 15.1

F180

Torque limit reach signals for butt–type reference position

setting

CLRCH1 to CLRCH4 f f 4.6

F182 Controlling signal (PMC axis control)

EACNT1 to

EACNT4

f f 15.1
