Series 0i - Model A Connection manual (Function) Page 149

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

4. REFERENCE POSITION ESTABLISHMENT

133

[Classification] Input signal

[Function] These signals decelerate the feedrate for manual reference position return

so that the reference position is approached at a low feedrate.

The deceleration signals are provided for axes in a one–to–one correspon-

dence. A number appended to a deceleration signal represents a con-

trolled axis number.

1 : Reference position return deceleration signal for the first axis

2 : Reference position return deceleration signal for the second axis

3 : Reference position return deceleration signal for the third axis

*DEC 1

[Operation] For the operation of the control unit in response to the deceleration signal,

see the description of the basic procedure for manual reference position

return.

[Classification] Output signal

[Function] These signals report that the tool is at the refernce position on a controlled

axis.

These siganls are provided for axes in a one–to–one corespondence.

A number appended to a signal represents a controlled axis number.

1 : Reference position return end signal for the first axis

2 : Reference position return end signal for the second axis

3 : Reference position return end signal for the third axis

ZP 1

[Output condition] These signals turn to “1” when:

D Manual reference position returns is completed, and the current

position is in the in–position area.

D Automatic reference position return (G28) is completed, and the

current position is in the in–position area.

D Reference position return check (G27) is completed, and the current

position is in the in–position area.

These signals turn to “0”when:

D The tool has moved from the reference position.

D An emergency stop is applied.

D A servo alarm is raised.

Reference position

return deceleration

signals *DEC1 to *DEC4

<X1009>

Reference position

return end signals ZP1 to

ZP4 <F094>
