14. MEASUREMENT

695

[Output condition] Each bit is set to 1 when:

D The high-speed skip signal is logical 1.

Each bit is set to 0 when:

D The high-speed skip signal is logical 0.

F122

#6 #5 #4 #3 #2 #1 #0

HDO0

6200

SRE

#5 #4

HSS

#3 #2 #1 #0

[Data type] Bit type

HSS 0 : The skip function does not use high-speed skip signals.

1 : The skip function uses high-speed skip signals.

SRE When a high-speed skip signal is used:

0 : The signal is considered to be input at the rising edge (0→1).

1 : The signal is considered to be input at the falling edge (1→0).

6201

#6 #5 #4

IGX

#3 #2 #1

SEB

SEA

[Data type] Bit type

SEA When a high speed skip signal goes on while the skip function is used,

acceleration/deceleration and servo delay are:

0 : Ignored.

1 : Considered and compensated (type A).

SEB When a high speed skip signal goes on while the skip function is used,

acceleration/deceleration and servo delay are:

0 : Ignored.

1 : Considered and compensated (type B).

IGX When the high-speed skip function is used, SKIP (bit 7 of X1004) and

SKIPP (bit 6 of G006) are:

0 : Enabled as skip signals.

1 : Disabled as skip signals.

NOTE

SKIPP (bit 6 of G006) is enabled only when bit 0 (GSK) of

parameter No. 6200 is set to 1. Note also that these signals

are enabled only for the T series.

Signal address

Parameter
