9. SPINDLE SPEED FUNCTION

419

CAUTION

1 Feed hold is invalid during spindle positioning.

2 Spindle positioning stops when emergency stop is applied;

restart with orientation operation.

3 Dry run, machine lock, and auxiliary function lock are not

available during spindle positioning.

4 The spindle positioning function and the serial spindle Cs

contour control function cannot be used together. If both

functions are used, positioning has priority.

5 Specify parameter No. 4962 even if semi-fixed angle

positioning is not used; otherwise M codes (M00 to M05) do

not work.

NOTE

1 Command spindle positioning with an independent block.

X- and Y-axis positioning cannot be commanded to the

same block.

2 Spindle positioning cannot be done by manual operation.

3 Automatic drift compensation is not effective for spindle

positioning. To adjust the amount of drift compensation for

each axis, set values manually and adjust the spindle

amplifier to minimize the spindle motor rotation at a voltage

of 0V. (parameter No. 3731). Insufficient adjustment

causes poor positioning accuracy. Drift compensation is not

needed with a serial spindle.

4 The machine coordinates for the spindle positioning axis

are displayed in pulses units.

OPERATOR’S MANUAL (For Lathe)

(B–63504EN)

SPINDLE POSITIONING FUNCTION

Caution

Note

Reference item
