Series 0i - Model A Connection manual (Function) Page 445

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

9. SPINDLE SPEED FUNCTION

429

1620 Time constant used in linear acceleration/deceleration or bell–shaped acceleration/

deceleration in rapid traverse for each axis

[Data type] Word axis

[Unit of data] ms

[Valid data range] 0 to 4000

Set the time constant used in linear acceleration/deceleration in rapid

traverse for each axis.

1820 Command multiply for each axis (CMR)

[Data type] Byte axis

D When command multiply is 1/2 to 1/27

Set value=

(Command multiply)

+100 [Valid data range: 102 to 127]

D When command multiply is 0.5 to 48

Set value = 2 command multiply [Valid data range: 1 to 96]

1826 In–position width for each axis

[Data type] Word axis

[Unit of data] Detection unit

[Valid data range] 0 to 32767

Set the in–position width for each axis.

1828 Positioning deviation limit for each axis in movement

[Data type] Two–word axis

[Unit of data] Detection unit

[Valid data range] 0 to 99999999

Set the positioning deviation limit in movement for each axis.

1829 Positioning deviation limit for each axis in the stopped state

[Data type] Word axis

[Unit of data] Detection unit

[Valid data range] 0 to 32767

Set the positioning deviation limit in the stopped state for each axis.

1851 Backlash compensation value used for rapid traverse for each axis

[Data type] Word axis

[Unit of data] Detection unit

[Valid data range] *9999 to +9999

Set the backlash compensation value for each axis.
