10. TOOL FUNCTIONS

B–63503EN–1/01

522

Memory for geometry compensation and wear compensation is prepared

separately. Geometry compensation and wear compensation can thus be

set separately.

Tool compensation

memory

Compensation amount

Geometry/wear com-

Geometry compensation

Geometry/wear com-

pensation

Wear compensation

#7 #6 #5 #4 #3 #2 #1 #0

3109 DWT

[Data type] Bit

DWT Characters G and W in the display of tool wear/geometry compensation

amount

0 : The characters are displayed at the left of each number.

1 : The characters are not displayed.

#7 #6 #5 #4 #3 #2 #1 #0

3290 GOF WOF

[Data type] Bit

WOF Setting the tool wear compensation value by MDI key input is:

0 : Not disabled

1 : Disabled (With parameter No. 3294 and No. 3295, set the offset

number range in which updating the setting is to be disabled.)

GOF Setting the tool geometry compensation value by MDI key input is:

0 : Not disabled

1 : Disabled (With parameter No. 3294 and No. 3295, set the offset

number range in which updating the setting is to be disabled.)

D Tool compensation

memory

Parameter
