Series 0i - Model A Connection manual (Function) Page 300

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

284

Number Message Description

109

FORMAT ERROR IN G08 A value other than 0 or 1 was specified af-

ter P in the G08 code, or no value was spe-

cified.

NOTE

In the advanced preview control mode, the functions listed

below cannot be specified. To specify these functions,

cancel the advanced preview control mode, specify the

desired function, then set advanced preview control mode

again.

⋅Rigid tapping function

⋅Cs contouring control function

⋅Feed per revolution

⋅One–digit F code feed

⋅Cylindrical interpolation function

⋅Involute interpolation function

⋅Exponential interpolation

⋅Normal direction control

⋅Polar coordinate command

⋅Index table indexing

⋅Threading and synchronous cutting

⋅Handle interruption

⋅Program restart

⋅Simple synchronous control

⋅Feed stop

⋅High–speed skip function

⋅Constant surface speed control

⋅Interrupt type custom macro

⋅Small–hole peck drilling cycle

⋅Automatic tool length measurement

⋅Skip cutting

⋅G28 (low–speed reference position return)

OPERATOR’S MANUAL

(For Machining Center)

(B–63514EN)

Look–ahead control (G08)

Alarm and message

Note

Reference item
