Series 0i - Model A Connection manual (Function) Page 471

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

9. SPINDLE SPEED FUNCTION

455

0450 SPINDLE MOTION ERROR

Spindle position deviation during rigid tapping

[Unit] Pulse

0451 SPINDLE MOTION PULSE

Number of pulses distributed to the spindle during rigid tapping

[Unit] Pulse

0452 RIGID ERROR

Momentary error difference between the spindle and tapping axis during

rigid tapping (signed)

[Unit] %

NOTE

This data item is displayed only when bit 0 (DGN) of

parameter No. 5204 is set to 1.

0453 RIGID ERROR(MAX)

Maximum error difference between the spindle and tapping axis during

rigid tapping (absolute value)

[Unit] %

NOTE

This data item is displayed only when bit 0 (DGN) of

parameter No. 5204 is set to 1.

0454 SPINDLE PULSE(SUM)

Cumulative number of pulses distributed to the spindle during rigid

tapping

[Unit] Pulse

Diagnosis screen

D Spindle position

deviation

D Number of pulses

distributed to the spindle

D Error difference between

the spindle and tapping

axis (momentary value)

D Error difference between

the spindle and tapping

axis (maximum)

D Cumulative number of

pulses distributed to the

spindle during rigid

tapping
