15. PMC CONTROL FUNCTION

757

8028

Linear acceleration/deceleration time constant for jog feed specified

by the speed command for each PMC–controlled axis

[Data type] Word axis type

[Unit of data] msec/1000 rpm

[Valid data range] 0 to 32767

Specify, for each PMC–controlled axis, the time needed to increase or

decrease the speed of the servo motor by 1000 rpm, that is, the time

constant of linear acceleration/deceleration for jog feed according to the

speed specified for that axis.

NOTE

If 0 is specified, the system does not control the

acceleration/deceleration.

A servo alarm or overtravel alarm for a PMC–controlled axis is detected

in the same way as an alarm for a CNC–controlled axis.

If an alarm occurs, the alarm is handled by applying the normal procedure,

alarm signal EIALg being set to “1” to inform the PMC of the alarm.

(If an overtravel alarm occurs, either negative overtravel signal EOTNg

or positive overtravel signal EOTPg is also set to “1”.)

If the PMC issues a command for a CNC–controlled axis, a P/S alarm No.

130 occurs.

Commands issued by the PMC are effective if the axis is in feed hold or

single block stop mode. The command results in the issue of an alarm if

cutting feed is executed with an override of 0%, or if the interlock is

enabled.

If the CNC issues a command for a PMC–controlled axis, a P/S alarm No.

130 occurs.

If the PMC issues a movement command for an axis in the plane of polar

coordinate interpolation in polar coordinate interpolation mode (G12.1),

a P/S alarm No. 130 occurs.

Alarm and message
