Series 0i - Model A Connection manual (Function) Page 26

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

1. AXIS CONTROL

NOTE

ROAx specifies the function only for a rotation axis (for

which ROTx, #0 of parameter No. 1006, is set to 1)

RABx In the absolute commands, the axis rotates in the direction

0 : In which the distance to the target is shorter.

1 : Specified by the sign of command value.

NOTE

RABx is valid only when ROAx is 1.

RRLx Relative coordinates are

0 : Not rounded by the amount of the shift per one rotation

1 : Rounded by the amount of the shift per one rotation

NOTE

1 RRLx is valid only when ROAx is 1.

2 Assign the amount of the shift per one rotation in parameter

No. 1260.

1260 Amount of a shift per one rotation of a rotation axis

NOTE

1 After setting the parameter, turn off the power once and turn

it on again to operate the machine.

2 This parameter is valid only when ROAx = 1.

[Data type] Two–word axis

Increment system Unit of data Standard value

IS–B 0.001 deg 360000

IS–C 0.0001 deg 3600000

[Valid data range] 1000 to 9999999

Set the amount of a shift per one rotation of a rotation axis.

[Unit of data]
