12. DISPLAY/SET/EDIT

633

The reading on the load meter can be displayed for each servo axis and

the serial spindle.

The reading on the load meter can be displayed for up to four servo axes

by setting parameters 3151 to 3154.

When serial spindles are used, the reading on the load meter and

speedmeter can be displayed only for the main serial spindle.

Although the speedmeter normally indicates the speed of the spindle

motor, it can also be used to indicate the speed of the spindle by setting

bit 6 (OPS) of parameter 3111 to 1.

#7 #6 #5 #4 #3 #2 #1 #0

3111 OPS OPM

[Data type] Bit

OPM Operating monitor

0 : Not displayed

1 : Displayed

OPS The speedmeter on the operating monitor screen indicates:

0 : Spindle motor speed

1 : Spindle speed

3151 Number of the axis for which the first load meter for the servo motor is used

3152 Number of the axis for which the second load meter for the servo motor is used

3153 Number of the axis for which the third load meter for the servo motor is used

3154 Number of the axis for which the 4th load meter for the servo motor is used

[Data type] Byte

[Valid data range] 0, 1, . . . , the number of control axes

Set the numbers of the axes for which measurement values on the load

meters for maximum four servo motors are displayed. Set 0 for those axes

for which a load meter need not be displayed.

2086 Rated current parameter (RTCURR)

[Data type] Word axis

12.1.13

Displaying Operating

Monitor

General

D Display of the servo axes

D Display of the spindle

axes

D Speedmeter

Parameter
