B–63503EN–1/01

A. INTERFACE BETWEEN CNC AND PMC

832

Group

Refer-

ence

item

series

Address Signal nameSymbol

M00 to M31 Miscellaneous function code signal F010 to F013 f f 8.1

M200 to M215 2nd M function code signal F014 to F015 f f 8.3

M300 to M315 3rd M function code signal F016 to F017 f f 8.3

MA CNC ready signal F001#7 f f 2.2

MABSM Manual absolute check signal F004#2 f f 5.4

MAFL Miscellaneousfunction lock check signal F004#4 f f 8.2

MBDT1,MBDT2to

MBDT9

Optional block skip check signal F004#0,F005 f f 5.5

MCFNA G071#3 f f

MCFNB

Power line switch completionsignal (serial spindle)

G075#3 f f

9.2

MD1,MD2,MD4 Mode selection signal G043#0 to #2 f f 2.6

MD1O Software operator's panel signal(MD1) F073#0 f f 12.1.14

MD2O Software operator's panel signal(MD2) F073#1 f f 12.1.14

MD4O Software operator's panel signal(MD4) F073#2 f f 12.1.14

MDRN Dry run check signal F002#7 f f 5.3.2

MEDT Memory edit select check signal F003#6 f f 2.6

MF Auxiliary function strobe signal F007#0 f f 8.1

MF2 2nd M function strobe signal F008#4 f f 8.3

MF3 3rd M function strobe signal F008#5 f f 8.3

MFIN Auxiliary function completionsignal G005#0 f f 8.4

MFIN2 2nd M function completion signal G004#4 f f 8.4

MFIN3 3rd M function completion signal G004#5 f f 8.4

MFNHGA

Main spindle MCC status signal while changing

G072#6 f f

MFNHGB

Main spindle MCC status signal while changing

spindles signal (serial spindle)

G076#6 f f

9.2

MH Manualhandle feed select check signal F003#1 f f 2.6

MI1 to MI4 Mirror image signal G106 f f 1.2.5

MINC Incremental feed select check signal F003#0 f f 2.6

MINP External program input start signal G058#0 f f 13.3

MJ JOG feed select check signal F003#2 f f 2.6

MLK All-axis machine lock signal G044#1 f f 5.3.1

MLK1 to MLK4 Each-axis machine lock signal G108 f f 5.3.1

MLKO Software operator's panel signal(MLK) F075#4 f f 12.1.14

MMDI Manual data input select check signal F003#3 f f 2.6

MMEM Automatic operationselect check signal F003#5 f f 2.6

MMI1 to MMI4 Mirror image check signal F108 f f 1.2.5
