B–63503EN–1/01

1. AXIS CONTROL

3622

Number of the pitch error compensation position at extremely positive posi-

tion for each axis

NOTE

After setting this parameter, turn the power off then on again

so that the setting will take effect.

[Data type] Word axis

[Unit of data] Number

[Valid data range] 0 to 1023

Set the number of the pitch error compensation position at the extremely

positive position for each axis.

NOTE

This value must be larger than set value of parameter (No.

3620).

3623 Magnification for pitch error compensation for each axis

NOTE

After setting this parameter, turn the power off then on again

so that the setting will take effect.

[Data type] Byte axis

[Unit of data] 1

[Valid data range] 0 to 100

Set the magnification for pitch error compensation for each axis.

If the magnification is set to 1, the same unit as the detection unit is used

for the compensation data.

3624 Interval between pitch error compensation positions for each axis

NOTE

After setting this parameter, turn the power off then on again

so that the setting will take effect.

[Data type] Two–word axis

Increment system IS–A IS–B IS–C Unit

Metric machine 0.01 0.001 0.0001 mm

Inch machine 0.001 0.0001 0.00001 inch

Rotation axis 0.01 0.001 0.0001 deg

[Unit of data]
