9. SPINDLE SPEED FUNCTION

402

[Classification] Output signal

[Function] This signal specifies that the spindle be clamped mechanically in a spindle

positioning sequence.

When this signal turns to 1, clamp the spindle on the machine (apply the

brakes or insert the pin).

[Output condition] Refer to the sequence (time chart) in this section.

[Classification] Input signal

[Function] This signal indicates that clamping the spindle is complete in response to

the spindle clamp signal SCLP.

Refer to 9.3 “Spindle Speed Control.”

Refer to the manual of serial spindle.

The spindle loop gain multiplier corresponding to the gear currently

selected by this signal is used. When the serial spindle is used, input gear

selection signals CTH1A and CTH2A, as well.

Relationship between the selected gear and spindle gear selection signal

Analog spindle

GR2 GR1 Selected gear

0 0 1st gear

0 1 2nd gear

1 0 3rd gear

1 1 4th gear

Serial spindle

CTH1A CTH2A Selected gear

0 0 HIGH

0 1 MEDIUM HIGH

1 0 MEDIUM LOW

1 1 LOW

Spindle clamp signal

SCLP <F038#0>

Spindle clamp

completion signal *SCPF

<G028#5>

Other signals

Gear selection signal

GR1, GR2, <G028#1, #2>

CTH1A, CTH2A

<G070#3, #2>
