9. SPINDLE SPEED FUNCTION
389
#7
8133
#6 #5 #4 #3 #2 #1 #0
SSC
NOTE
When this parameter has been set, the power must be
turned off before operation is continued.
[Data type] Bit
SSC Specifies whether to use constant surface speed control, as follows:
0 : Not to use.
1 : Use.
3741 Maximum spindle speed for gear 1
3742 Maximum spindle speed for gear 2
3743 Maximum spindle speed for gear 3
3744 Maximum spindle speed for gear 4
[Data type] Word
[Unit of data] min
–1
Set the maximum spindle speed for each gear.
3770 Axis as the calculation reference in constant surface speed contorol
[Data type] Byte
[Valid data range] 0, 1 to number of control axes
set the axis as the calculation reference in constant surface speed contorol.
NOTE
When 0 is set, constant surface speed control is always
applied to the X–axis. In this case, specifying P in a G96
block has no effect on the constant surface speed control.
3771 Minimum spindle speed in constant surface speed control mode (G96)
[Data type] Word
[Unit of data] min
–1
[Valid data range] 0 to 32767
Set the minimum spindle speed in the constant surface speed control
mode (G96).
The spindle speed in constant surface speed control is clamped to the
speed given by parameter 3771.
