Series 0i - Model A Connection manual (Function) Page 265

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

249

1403

#6 #5 #4 #3 #2 #1 #0

MIF

NOTE

When this parameter has been set, the power must be

turned off before operation is continued.

[Data type] Bit

MIF Cutting feedrates at feed per minute is specified by F commands

0 : In units of 1 mm/min for millimeter machines or 0.01 inches/min for

inch machines.

1 : In unit of 0.001 mm/min for millimeter machines or 0.00001

inches/min for inch machines.

NOTE

M series are not equipped with this parameter. Cutting

feedrates are specified by F commands in units of 0.001

mm/min for millimeter machines or 0.00001 inches/min for

inch machines.

3401

#6 #5 #4 #3 #2 #1

FCD

[Data type] Bit

FCD When an F command and a G command (G98, G99) for feed per minute or

feed per rotation are specified in the same block, and the G command

(G98, G99) is specified after the F command, the F command is:

0 : Assumed to be specified in the mode (G98 or G99) when the F

command is specified

1 : Assumed to be specified in the mode of the G command (G98 or G99)

of the same block

Parameter
