B–63503EN–1/01

9. SPINDLE SPEED FUNCTION

511

This function stops the spindle at a specified position. The spindle can

be stopped in either of the following two ways.

· The spindle is mechanically stopped by using stoppers.

· The spindle is stopped by applying a function of the spindle control

unit.

To mechanically stop the spindle by using, for example, a stopper, rotate

the spindle at a constant low speed and drive a stopper or pin into the

spindle. The spindle can be rotated at a constant speed by applying either

of the following methods.

· Spindle orientation signal (See 9.3, “Spindle Control.”)

· Spindle output control by the PMC (See 15.4.)

Some spindle control units can position the spindle motor by using

sensors and position coders. The CNC itself does not control positioning

by using these units.

In serial spindle orientation by a position coder, the stop position is

specified either by a parameter or by the PMC (spindle orientation

function with the stop position externally set).

[Classification] Input signal

[Function] This command is used for specifying a stop position with an absolute

position within one rotation in the following equation:

4096

360

ȍ (2

Pi)

i=0

9.12

SPINDLE

ORIENTATION

General

Mechanical stop

Using the spindle

control unit

Serial spindle orientation

by a position coder

Signal

Spindle orientation

signals with the stop

position externally set

SHA00 to SHA11 for the

first spindle

<G078, G079>

SHB00 to SHB11 for the

second spindle

<G080, G081>
