Series 0i - Model A Connection manual (Function) Page 858

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

A. INTERFACE BETWEEN CNC AND PMC

842

Address

Refer-

ence

Item

series

Symbol Signal name

G058#1 External read start signal EXRD f f 13.2

G058#2 External read/punch stop signal EXSTP f f 13.2

G058#3 External punch start signal EXWT f f 13.2

G061#0 Rigid tapping signal RGTAP f f 9.10

G061#4,#5 Rigid tap spindle select signal RGTSP1, RGTSP2 f - 9.10

G062#1 Automatic erase CRT screen display cancel signal *CRTOF f f 12.1.17

G066#0 All-axis VRDY OFF alarm ignore signal IGNVRY f f 2.8

G066#1 External key input mode selection signal ENBKY f f 15.5

G066#7 Key code read signal EKSET f f 15.5

G070#0 Torque limit commandLOW signal (serial spindle) TLMLA f f 9.2

G070#1 Torque limit commandHIGH signal (serial spindle) TLMHA f f 9.2

G070#3,#2 Clutch/gear signal (serial spindle) CTH1A,CTH2A f f 9.2

G070#4 CCW command signal (serial spindle) SRVA f f 9.2

G070#5 CW command signal (serial spindle) SFRA f f 9.2

G070#6 Orientation command signal (serial spindle) ORCMA f f 9.2

G070#7 Machine ready completion signal (serial spindle) MRDYA f f 9.2

G071#0 Alarm reset signal (serial spindle) ARSTA f f 9.2

G071#1 Emergency stop signal (serial spindle) *ESPA f f 9.2

G071#2 Spindle select signal (serial spindle) SPSLA f f 9.2

G071#3 Power line switch completion signal (serial spindle) MCFNA f f 9.2

G071#4 Soft start stop cancel signal (serial spindle) SOCNA f f 9.2

G071#5 Signal for controllingvelocity integration (serial spindle) INTGA f f 9.2

G071#6 Output switch request signal (serial spindle) RSLA f f 9.2

G071#7 Power line status check signal (serial spindle) RCHA f f 9.2

G072#0 Orientation stop position change signal (serial spindle) INDXA f f 9.2

G072#1

Rotation direction command while changing the

orientation stop position signal (serial spindle)

ROTAA f f 9.2

G072#2

Short–distant movement command while changing the

orientation stop position signal (serial spindle)

NRROA f f 9.2

G072#3 Differential mode command signal (serial spindle) DEFMDA f f 9.2

G072#4 Analog override command signal (serial spindle) OVRIDA f f 9.2

G072#5

Incremental command external setting type orientation

signal (serial spindle)

INCMDA f f 9.2

G072#6

Main spindle MCC status signal while changing spindles

signal (serial spindle)

MFNHGA f f 9.2

G072#7

High–output MCC status signal while a magnetic sensor

(serial spindle)

RCHHGA f f 9.2

G073#0

Command for spindle orientaion with a magnetic sensor

(serial spindle)

MORCMA f f 9.2

G073#1 Slave operation command signal (serial spindle) SLVA f f 9.2

G073#2 Motor power stop signal (serial spindle) MPOFA f f 9.2
