Series 0i - Model A Connection manual (Function) Page 417

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

9. SPINDLE SPEED FUNCTION

401

G code system A G code system B, C

Command method

Address used

Command of

A!B on the

above Fig.

Address used

and G–code

Command of

A!B on the

above Fig.

Absolute

command

Direct the end

point position by

the distance from

the program

origin.

C C180.0 ; G90,C G90C180.0 ;

Incremental

command

Command by the

distance between

the start and end

points.

H H90.0 ; G91,C G91C90.0 ;

Spindle positioning is done at the rapid traverse rate specified by

parameter No. 1420, to which linear acceleration deceleration are applied.

Overrides of 100%, 50%, 25% and F0 (parameter No. 1421) are also

applied.

A specific M code (parameter no. 4961) must be set when the mode is

changed from spindle positioning to normal spindle rotation.

[Classification] Input signal

[Function] When this signal is 1, the CNC orients and positions the spindle.

[Classification] Output signal

[Function] This signal specifies that spindle mechanical clamping be released in a

spindle positioning sequence.

When this signal is output, unclamp the spindle on the machine (release

the brakes or extract the pin).

[Output condition] Refer to the sequence (time chart) in this section.

[Classification] Input signal

[Function] This signal indicates that unclamping the spindle is complete in response

to the spindle unclamp signal SUCLP.

D Spindle positioning

feedrate

D Spindle positioning reset

Signal

Spindle stop complete

signal SPSTP

<G028#6>

Spindle unclamp signal

SUCLP <F038#1>

Spindle unclamp

completion signal

*SUCPF <G028#4>
