7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

303

CAUTION

1 When the total distance for the blocks under Look–ahead

control is equal to or less than the deceleration distance

from the current feedrate, deceleration starts. When

Look–ahead control has proceeded upon the completion of

deceleration, and the total distance for the blocks

increases,acceleration starts. Especially, when a series of

blocks containing very small amounts of travel are specified,

deceleration and acceleration may be alternated, which

prevents the feedrate from becoming constant. In such a

case, specify a lower feedrate.

2 When the dry run signal is inverted from 0 to 1 or from 1 to

0 during movement along an axis, the speed of movement

is increased or reduced to a specified speed without first

being reduced to zero.

3 When a no–movement block or a one–shot G code such as

G04 is encountered in Look–ahead control (Multiple blocks

are read in advance) mode, the movement is decelerated

and halted in the preceding block.

NOTE

1 As acceleration after interpolation, use linear acceleration.

Exponential acceleration/deceleration cannot be used.

2 Upon switching to Look–ahead control (Multiple blocks are

read in advance) mode, all manual handle interrupts are

ignored.

OPERATOR’S MANUAL

(For Machining Center)

(B–63514EN)

Look–ahead control (Multiple blocks are read in advance)

Caution

Note

Reference item
