5. AUTOMATIC OPERATION

B–63503EN–1/01

192

By starting automatic operation during the DNC operation mode (RMT),

it is possible to perform machining (DNC operation) while a program is

being read in via the reader/puncher interface. It is possible to select files

(programs) saved in an external input/output unit of a floppy format

(Handy File, Floppy Cassettes, or FA card) and specify (schedule) the

sequence and frequency of execution for automatic operation.

To use the DNC operation function, it is necessary to set the parameters

related to the reader/puncher interface in advance.

[Classification] Input signal

[Function] Selects the DNC operation mode (RMT).

To select the DNC operation mode (RMT), it is necessary to select the

memory operation mode (MEM) and set the DNC operation select signal

to “1”.

[Operation] When the DNC operation select signal becomes “1”, the control unit

operates as follows:

– If the memory mode (MEM) has not been selected, the signal is

ignored, and nothing happens.

– If the memory operation mode (MEM) has been selected, the DNC

operation mode (RMT) is selected, and DNC operation becomes

possible. In this case, the DNC operation selection confirm signal

MRMT becomes “1”.

[Classification] Output signal

[Function] Indicates that the DNC operation mode (RMT) has been selected.

[Output condition] The DNC operation selection confirm signal becomes “1” when:

– The DNC operation mode (RMT) is selected.

The DNC operation selection confirm signal becomes “0” when:

– The DNC operation mode (RMT) is not selected.

5.9

DNC OPERATION

General

Signal

DNC operation select

signal

DNCI<G043#5>

DNC operation selection

confirm signal

MRMT<F003#4>
