Series 0i - Model A Connection manual (Function) Page 644

Connection manual (Function)
12. DISPLAY/SET/EDIT
B–63503EN–1/01
628
6753 Integrated value of cutting time
Setting entry is acceptable.
[Data type] Two–word
[Unit of data] One ms
[Valid data range] 0 to 60000
6754 Integrated value of cutting time
Setting entry is acceptable.
[Data type] Two–word
[Unit of data] One min
[Valid data range] 0 to 99999999
This parameter displays the integrated value of a cutting time that is
performed in cutting feed such as linear interpolation (G01) and circular
interpolation (G02 or G03).
The actual cutting time is the sum of the values set in parameter Nos. 6753
and 6754.
6755
Integrated value of general–purpose integrating meter drive signal (TMRON) ON
time
Setting entry is acceptable.
[Data type] Two–word
[Unit of data] One ms
[Valid data range] 0 to 60000
6756
Integrated value of general–purpose integrating meter drive signal (TMRON) ON
time
Setting entry is acceptable.
[Data type] Two–word
[Unit of data] One min
[Valid data range] 0 to 99999999
This parameter displays the integrated value of a time while input signal
TMRON from PMC is on.
The actual integrated time is the sum of the values set in parameter Nos.
6755 and 6756.
