Series 0i - Model A Connection manual (Function) Page 843

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

A. INTERFACE BETWEEN CNC AND PMC

827

Group

Refer-

ence

item

series

Address Signal nameSymbol

CDZ Chamferring signal G053#7 f - 11.8

CFINA F046#1 f f

CFINB

Spindle switch completion signal (serial spindle)

F050#1 f f

9.2

CHPA F046#0 f f

CHPB

Power line switch signal (serial spindle)

F050#0 f f

9.2

C CLRCH1 to CLRCH4

Torque limit reach signals for butt–type reference

position setting

F180 f f 4.6

CON Cs contour control change signal G027#7 f f 9.8

CSS Constant surface speed signal F002#2 f f 9.4

CTH1A,CTH2A G070#3,#2 f f

CTH1B,CTH2B

Clutch/gear signal (serial spindle)

G074#3,#2 f f

9.2

CUT Cutting feed signal F002#6 f f 2.7

DEFMDA G072#3 f f

DEFMDB

Differential mode command signal (serial spindle)

G076#3 f f

9.2

DEN Distribution end signal F001#3 f f 8.1

DM00 F009#7 f f

DM01 F009#6 f f

DM02

Decode M signal

F009#5 f f

8.1

DM30 F009#4 f f

DMMC Direct operationselect signal G042#7 f f 15.6

DNCI DNC operation select signal G043#5 f f 5.9

DRN Dry run signal G046#7 f f 5.3.2

DRNE Dry run signal (PMC axis control) G150#7 f f 15.1

DRNO Software operator's panel signal(DRN) F075#5 f f 12.1.14

EA0 to EA6 Address signal for external data input G002#0 to #6 f f 15.2

EABUFA F131#1 f f

EABUFB F134#1 f f

EABUFC

Buffer full signal (PMC axis control)

F137#1 f f

15.1

EABUFD F140#1 f f

EACNT1 to EACNT4 Controlling signal (PMC axis control) F182 f f 15.1

EADEN1 to EADEN4 Distributioncompletionsignal(PMC axis control) F112 f f 15.1

EAX1 to EAX4 Control axis select signal (PMC axis control) G136 f f 15.1

EBSYA F130#7 f f 15.1

EBSYB

Axis control command read completion signal

F133#7 f f 15.1

EBSYC

Axis control command read completion signal

(PMC axis control)

F136#7 f f 15.1

EBSYD F139#7 f f 15.1
