Series 0i - Model A Connection manual (Function) Page 297

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

281

1771

Parameter 2 for setting an acceleration for linear acceleration/deceleration before

interpolation in the advanced preview control mode (time used to reach the maxi-

mum machining speed during linear acceleration/deceleration before interpolation)

[Data type] Word

[Unit of data] 1 ms

[Valid data range] 0 to 4000

This parameter is used to set an acceleration for linear acceleration/decel-

eration before interpolation in the advanced preview control mode. In this

parameter, set the time (time constant) used to reach the speed set in pa-

rameter No. 1770.

CAUTION

1 When 0 is set in parameter No. 1770 or parameter No. 1771,

linear acceleration/deceleration before interpolation is

disabled.

2 In parameter Nos. 1770 and 1771, set values that satisfy the

following: Parameter No. 1770/Parameter No. 1771

1777

Minimum speed for the automatic corner deceleration function

(for the advanced preview control)

[Data type] Word axis

Increment system

Unit of data

Valid data range

Increment s

stem

Unit of data

IS-B IS-C

Millimeter machine 1 mm/min 6 – 15000 6 – 12000

Inch machine 0.1 inch/min 6 – 6000 6 – 4800

Rotation axis 1 deg/min 6 – 15000 6 – 12000

Set a speed at which the number of buffered pulses in deceleration is as-

sumed to be 0 when linear acceleration/deceleration before interpolation

is used.

1779

Critical angle subtended by two blocks for automatic corner deceleration

(for the advanced preview control)

[Data type] Two–word

[Unit of data] 0.001 deg

[Valid data range] 0 to 180000

Set a critical angle to be subtended by two blocks for corner deceleration

when the angle–based automatic corner deceleration function is used.

The angle subtended by two blocks is defined as q in the examples shown

below.

[Unit of data]

[Valid data range]
