Series 0i - Model A Connection manual (Function) Page 860

Connection manual (Function)
B–63503EN–1/01
A. INTERFACE BETWEEN CNC AND PMC
844
Address
Refer-
ence
Item
M
series
T
series
Symbol Signal name
G110 +LM1 to +LM4 - f
G112
Stroke limit external setting signal
-LM1 to -LM4 - f
2.3.2
G114 *+L1 to *+L4 f f
G116
Overtravel signal
*-L1 to *-L4 f f
2.3.1
G118 *+ED1 to *+ED4 f f
G120
External decelerationsignal
*-ED1 to *-ED4 f f
7.1.8
G126 Servo off signal SVF1 to SVF4 f f 1.2.7
G130 Interlock signal for each axis *IT1 to *IT4 f f 2.5
G132#0 to #3 +MIT1 to +MIT4 - f
G134#0 to #3
Interlock signal for each axis and direction
-MIT1 to -MIT4 - f
2.5
G136 Control axis select signal (PMC axis control) EAX1 to EAX4 f f 15.1
G138 Simple synchronous axis select signal SYNC1 to SYNC4 - f 1.6
G140 Simple synchronous manual feed axis select signal SYNCJ1 to SYNCJ4 - f 1.6
G142#0 Auxiliary function completionsignal (PMC axis control) EFINA f f 15.1
G142#2 Buffering disable signal (PMC axis control) EMBUFA f f 15.1
G142#3 Block stop signal (PMC axis control) ESBKA f f 15.1
G142#4 Servo off signal (PMC axis control) ESOFA f f 15.1
G142#5 Axis control temporary stop signal (PMC axis control) ESTPA f f 15.1
G142#6 Reset signal (PMC axis control) ECLRA f f 15.1
G142#7 Axis control command read signal (PMC axis control) EBUFA f f 15.1
G143#0 to #6 Axis control command signal (PMC axis control) EC0A to EC6A f f 15.1
G143#7 Block stop disable signal (PMC axis control) EMSBKA f f 15.1
G144,G145 Axis control feedrate signal (PMC axis control) EIF0A to EIF15A f f 15.1
G146 to G149 Axis control data signal (PMC axis control) EID0A to EID31A f f 15.1
G150#0,#1 Rapid traverse override signal (PMC axis control) ROV1E,ROV2E f f 15.1
G150#5 Override cancel signal (PMC axis control) OVCE f f 15.1
G150#6 Manual rapid traverse selection signal (PMC axis control) RTE f f 15.1
G150#7 Dry run signal (PMC axis control) DRNE f f 15.1
G151 Feedrate override signal (PMC axis control) *FV0E to *FV7E f f 15.1
G154#0 Auxiliary function completionsignal (PMC axis control) EFINB f f 15.1
G154#2 Buffering disable signal (PMC axis control) EMBUFB f f 15.1
G154#3 Block stop signal (PMC axis control) ESBKB f f 15.1
G154#4 Servo off signal (PMC axis control) ESOFB f f 15.1
G154#5 Axis control temporary stop signal (PMC axis control) ESTPB f f 15.1
G154#6 Reset signal (PMC axis control) ECLRB f f 15.1
G154#7 Axis control command read signal (PMC axis control) EBUFB f f 15.1
G155#0 to #6 Axis control command signal (PMC axis control) EC0B to EC6B f f 15.1
G155#7 Block stop disable signal (PMC axis control) EMSBKB f f 15.1
G156,G157 Axis control feedrate signal (PMC axis control) EIF0B to EIF15B f f 15.1
