B–63503EN–1/01

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

253

When a one–digit number from 1 to 9 is specified after F, the feedrate set

for that number in a parameter (Nos. 1451 to 1459) is used. When F0 is

specified, the rapid traverse rate is applied.

The feedrate corresponding to the number currently selected can be

increased or decreased by turning on the switch for changing F1–digit

feedrate on the machine operator’s panel, then by rotating the manual

pulse generator.

The increment/decrement, ∆F, in feedrate per scale of the manual pulse

generator is as follows:

F +

Fmax

100X

∆

Fmax : feedrate upper limit for F1–F4 set by parameter 1460, or

feedrate upper limit for F5–F9 set by parameter 1461

X : any value of 1–127 set by parameter 1450

The feedrate set or altered is kept even while the power is off. The current

feedrate is displayed on the screen.

[Classification] Input signal

[Function] Increases or decreases F1-digit speed set by the parameters No. 1451 to

1459 using the manual pulse generator.

Since the manual pulse generator may also be used for axis feeding, signal

F1D (G016#7) designates which function may be used.

[Operation] When the signal is “1”, the F1–digit speed can be increased/decreased

using the manual pulse generator.

F1DG016

#6 #5 #4 #3 #2 #1 #0

7.1.5

F1-digit Feed

(M series)

General

Signal

F1-digit feed select signal

F1D <G016#7>

Signal address
