Series 0i - Model A Connection manual (Function) Page 51

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

1. AXIS CONTROL

#7 #6 #5 #4 #3 #2 #1 #0

1800 RBK

[Data type] Bit

RBK Backlash compensation applied separately for cutting feed and rapid

traverse

0 : Not performed

1 : Performed

1851 Backlash compensating value for each axis

[Data type] Word axis

[Unit of data] Detection unit

[Valid data range] –9999 to +9999

Set the backlash compensating value for each axis.

When RBK is 1, set the backlash compensating value for cutting feed.

When the machine moves in the direction opposite to the reference

position return direction after the power is turned on, the first backlash

compensation is performed.

1852 Backlash compensating value used for rapid traverse for each axis

[Data type] Word axis

[Unit of data] Detection unit

[Valid data range] –9999 to +9999

Set the backlash compensating value used in rapid traverse for each axis.

This parameter is valid when RBK is set to 1.

CAUTION

The backlash compensation for each rapid traverse and

cutting feed is not performed until the first reference position

return is completed after the power is turned on. Under this

state, the normal backlash compensation is performed

according to the value specified in parameter No. 1851

irrespective of a rapid traverse and a cutting feed.

NOTE

When backlash compensation is applied separately for

cutting feed and rapid traverse, jog feed is regarded as

cutting feed.

Parameter

Caution

Note
