9. SPINDLE SPEED FUNCTION

509

D A spindle–phase synchronous control command is effective only in

synchronous spindle control mode. The specified phase can be

repeatedly changed under synchronous control.

See the manual of serial spindles.

#7 #6 #5 #4 #3 #2 #1 #0

8133 SYC

NOTE

When this parameter has been set, the power must be

turned off before operation is continued.

[Data type] Bit

SYC Specifies whether to use spindle synchronous control, as follows :

0 : Not to use.

1 : Use.

#7 #6 #5 #4 #3 #2 #1 #0

4800 ND2 ND1

[Data type] Bit type

ND1 In controlling the spindle synchronization, the direction of the first

spindle (master spindle) motor rotation is:

0 : The direction indicated by the command sign

1 : The opposite direction to that indicated by the command sign

ND2 In controlling the spindle synchronization, the direction of the 2nd

spindle (slave spindle) motor rotation is:

0 : The direction indicated by the command sign

1 : The opposite direction to that indicated by the command sign

4810 Error pulse between two spindles when synchronizing phases in the serial spindle

synchronization control mode

[Data type] Byte type

[Unit of data] Pulse

[Valid data range] 0 to 255

Set the difference in error pulses between two spindles when synchroniz-

ing phases in the serial spindle synchronization control mode.

When the difference in error pulse between two spindles is within the

value set in this parameter, the spindle phase synchronization completion

signal FSPPH <F044#3> becomes “1”.

This parameter is used to check the difference in phase in synchronization

control and to confirm the completion of synchronization in the serial

spindle synchronization control mode.
