9. SPINDLE SPEED FUNCTION

407

#7 #6 #5 #4 #3 #2 #1 #0

8133 AXC

[Data type] Bit

AXC Specifies whether to use spindle positioning, as follows :

0 : Not to use.

1 : Use.

NOTE

It is impossible to select spindle positioning–based Cs

contour control and serial spindle–based Cs contour control

at the same time.

#7 #6 #5 #4 #3 #2 #1 #0

1006 ZMIx

[Data type] Bit axis

ZMIx The direction of reference position return and the direction of initial

backlash at power–on

0 : Positive direction

1 : Negative direction

NOTE

When the serial spindle is being used, this parameter is

invalid for the spindle positioning axis.

1020 Name of the axis used for programming for each axis

[Data type] Byte axis

Set the name of the program axis for each control axis, with one of the

values listed in the following table:

Axis name Set value Axis name Set value Axis name Set value

X 88 U 85 A 65

Y 89 V 86 B 66

Z 90 W 87 C 67

NOTE

1 In the T series, when G code system A is used, neither U,

V, nor W can be used as an axis name. Only when G code

system B or C is used, U, V, and W can be used as axis

names.

2 The same axis name cannot be assigned to more than one

axis.

The axis name of spindle positioning is C axis.
