11. PROGRAM COMMAND

B–63503EN–1/01

568

In some canned cycles, a spindle command to rotate the spindle in reverse

direction may be output.

The following canned cycles require spindle control:

M series T series

Reverse tapping cycle G74 Face tapping cycle (G84)

Fine boring cycle G76 Side tapping cycle (G88)

Tapping cycle G84

Boring cycle G86

Back boring cycle G87

Boring cycle G88

For spindle control, the following normal miscellaneous functions are

used:

See the description of the miscellaneous functions.

M03: CW spindle rotation

M04: CCW spindle rotation

M05: Spindle stop

M19: Spindle orientation (M series)

When the rotation direction of the spindle is to be switched from one

direction to the other (for example, when M04 is output during M03

operation), a parameter can specify whether to send M05 at the time

switching.

Timing charts are described in the following page:

SPINDLE CONTROL
