12. DISPLAY/SET/EDIT

B–63503EN–1/01

620

3120 Time from the output of an alarm to the termination of sampling (waveform diagno-

sis function)

[Data type] Word

[Unit of data] ms

[Valid data range] 1 to 32760

This parameter specifies the time allowed from the time a servo alarm

condition occurs until data collection and recording are stopped in the

waveform diagnosis function; data collection can be continued

additionally for the specified time.

NOTE

1 Once the memory area becomes full, the oldest data is

deleted to allow new data to be recorded (stored type).

2 Waveform diagnosis data is held in memory even after the

power is turned off (stored type).

3 Be careful to set the date and time correctly.

4 Waveform diagnosis is enabled when bit 0 (SGD) of

parameter No. 3112 is set to 1. To perform waveform

diagnosis, a graphics display circuit is required.

Usual graphic display function can not be used when

waveform diagnosis function is enable.

MAINTENANCE MANUAL (B–63505EN) Waveform diagnostic display

Note

Reference item
