9. SPINDLE SPEED FUNCTION

373

[Classification] Input signal

[Function] The SAR signal initiates cutting feed. In other words, if the signal is

logical 0, cutting feed will not start.

[Operation] Generally, this signal is used to inform the CNC that the spindle has

reached the specified speed.

For this purpose, the signal must be set to 1 only after the actual speed of

the spindle has reached the specified speed.

Setting parameter No. 3740 with a wait time before the start of checking

the SAR signal inhibits cutting feed from starting under a condition of

SAR = 1 specified before the change of the spindle command.

To use the SAR signal, it is necessary to set bit 0 (SAR) of parameter No.

3708 to 1.

The CNC checks the SAR signal under the following conditions:

a. Bit 0 (SAR) of parameter No. 3708 is set to 1.

b. Before starting distribution of the first feed (move command) block

after shifting from the rapid traverse mode to the cutting feed mode.

This checking is performed after the time set by parameter No. 3740

has elapsed after the feed block is read.

c. Before starting distribution of the first feed command block after an

S code is commanded. The wait time for checking is the same as in

item b.

d. When an S code and feed are programmed in the same block, the S

code (or command output to the spindle) is output, and the SAR signal

is checked after a fixed time elapses. If the SAR signal is set to “1”,

feed begins.

CAUTION

According to the conditions of item d above, note that if the

circuit is so designed that SAR is turned to “0”

simultaneously with the output of an S code and the change

of spindle speed is gated with DEN signal, the operation will

stop. That is, the spindle speed does not reach the

commanded speed because the CNC is waiting for the DEN

signal and distribution is not started because the CNC is

waiting for the SAR signal.

Spindle speed arrival

signal SAR <G029#4>
