9. SPINDLE SPEED FUNCTION

364

GR30

GR20GR10

10V

ABC

Spindle speed

command

(S code input)

A×

Vmin

4095

C×

Vmax

4095

B×

Vmaxh

4095

A×

Vmaxl

4095

VC: Voltage corresponding to the upper limit of output value to spindle motor.

VH: Voltage corresponding to the upper limit of output value to spindle motor with high-speed gears (medium

speed gear for 3-stage gear)

VL: Voltage corresponding to the upper limit of output value to spindle motor at low-speed gear

Spindle motor speed command

(analog voltage output)

Fig. 9.3 (c) M type gear change B

When using this function, set the following parameters:

· Constant Vmax (Parameter No.3736) related to the upper limit of

spindle motor speed (min

–1

)

Upper limit of spindle motor speed (min

–1

)

Spindle motor speed (min

–1

) when the command voltage is 10V

Vmax = 4095×

· Constant Vmin (Parameter No. 3735) related to the lower limit of

spindle motor speed (min

–1

)

Vmin = 4095×

Lower limit of spindle motor speed (min

–1

)

Spindle motor speed (min

–1

) when the command voltage is 10V

· Constant Vmaxl (Parameter No. 3751) related to the upper limit of

spindle motor speed (min

–1

) with low-speed gears

Vmaxl = 4095×

Upper limit of spindle motor speed (min

–1

) with low-speed gears

Spindle motor speed (min

–1

) when the command voltage is

10V

· Constant Vmaxh (Parameter No. 3752) related to the upper limit of

spindle motor speed (min

–1

) with high-speed gears (medium-speed

gear for 3-stage gear)

Vmaxh = 4095×

Upper limit of spindle motor speed (min

–1

) with high-speed gears

(medium-speed gear for 3-stage gear)

Spindle motor speed (min

–1

) when the command voltage is 10V
