5. AUTOMATIC OPERATION

B–63503EN–1/01

170

3017 Output time of reset signal RST

[Data type] Byte

[Unit of data] 16 ms

[Valid data range] 0 to 255

To extend the output time of reset signal RST, the time to be added is

specified in this parameter.

RST signal output time = time required for reset + parameter value

16 ms

MCL3203

#6 #5 #4 #3 #2 #1 #0

[Data type] Bit

MCL Whether a program prepared in the MDI mode is cleared by reset

0: Not deleted

1: deleted

3402

CLR

#5 #4 #3 #2 #1 #0

[Data type] Bit

CLR Reset key on the MDI panel, external reset signal, reset and rewind signal,

and emergency stop signal

0: Cause reset state.

1: Cause clear state.

CLV6001

CCV

#5 #4 #3 #2 #1 #0

[Data type] Bit

CCV Custom macro’s common variables Nos. 100 through 199

0: Cleared to “vacant” by reset

1: Not cleared by reset

CLV Custom macro’s local variables Nos. 1 through 33

0: Cleared to “vacant” by reset

1: Not cleared by reset

OPERATOR’S MANUAL

(For Machining Center)

(B–63514EN)

STATUS WHEN TURNING POWER ON, WHEN CLEAR AND

WHEN RESET

OPERATOR’S MANUAL

(For Lathe) (B–63504EN)

STATUS WHEN TURNING POWER ON, WHEN CLEAR AND

WHEN RESET

Reference item

Contents Summary of Series 0i - Model A Connection manual (Function)
