Series 0i - Model A Connection manual (Function) Page 303

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

287

Feed functions f : Can be programmed

: Cannot be programmed

Name

Description

Rapid traverse rate Up to 240 m/min (0.01 mm)

Up to 100 m/min (0.0001 mm)

Rapid traverse rate override F0, 25, 50, 100 %

Rapid traverse rate override

in units of 1%

0% to 100 %

Feed per minute (G94)

Feed per rotation (G95)

Rapid traverse bell–shaped

acceleration/deceleration

Cutting feed linear accelera-

tion/deceleration before inter-

polation

Feedrate override 0% to 254%

Feed by F command with

one digit

Inverse time feed (G93)

External deceleration

Tool compensation functions f : Can be programmed

: Cannot be programmed

Name

Description

Cutter compensation C

(G40, G41, G42)

Tool length compensation

(G43, G44, G49)

Program input f : Can be programmed

: Cannot be programmed

Name

Description

Plane selection

(G17, G18, G19)

Local coordinate system

(G52)

f *

Workpiece coordinate system

(G54 to G59) (G54.1Pxx)

f *

Workpiece coordinate system

(G92)

f *

Workpiece coordinate system

preset (G92.1)

f *

Interrupt–type custom macro
