B–63503EN–1/01

11. PROGRAM COMMAND

541

Numerical values can be entered with a decimal point. A decimal point

can be used when entering a distance, time, or speed. Decimal points can

be specified with the following addresses:

X, Y, Z, U, V, W, A, B, C, I, J, K, Q, R, F M series

. . . . . . . . . . . . . . . . . . .

X, Y, Z, U, V, W, A, B, C, I, J, K, R, F. T series. . . . . . . . . . . . . . . . .

There are two types of decimal point notation: calculatorĆtype notation

and standard notation.

When calculatorĆtype decimal point notation is used, a value without

decimal point is considered to be specified in millimeters, inches or

degree. When standard decimal point notation is used, such a value is

considered to be specified in least input increments. Select either

calculatorĆtype or standard decimal point notation by using the DPI bit

(bit 0 of parameter 3401). Values can be specified both with and without

decimal point in a single program.

Program command Pocket calculator

type decimal point

programming

Standard type decimal

point programming

X1000

Command value with-

out decimal point

1000mm

Unit : mm

1mm

Unit : Least input increment

(0.001 mm)

X1000.0

Command value with

decimal point

1000mm

Unit : mm

1000mm

Unit : mm

#7 #6 #5 #4 #3 #2 #1 #0

3401 DPI

[Data type] Bit

DPI When a decimal point is omitted in an address that can include a decimal

point

0 : The least input increment is assumed.

1 : The unit of mm, inches, degree, or s is assumed. (Pocket calculator

type decimal point programming)

11.1

DECIMAL POINT

PROGRAMMING/

POCKET

CALCULATOR TYPE

DECIMAL POINT

PROGRAMMING

General

Parameter
